Prefabricated Frame with Bushes

The scaffolding system with bushes is made up of frames with a bush coupling system for positioning ledgers and diagonals.

Features

Steel: S235JR
Diameter tube: 48.3 mm x 2.90mm
Coupling: bushes
Spans: 180, 250 cm
Authorization for construction loads up to: 300 daN/mq (cl 4)
Steel decks capacity up to 600 daN/mq (cl 6).
Certifications: Ministry Authorizations, EN12810.

The system

Due to its simple assembly it is widely used by construction companies. Tube and coupler scaffolding can be integrated for special operations. The elements of the prefabricated scaffolding were designed for a simple and safe assembly. The wide range of accessories allows the design of designs meeting the most sophisticated and complex construction and architectural techniques.

All the elements of the scaffolding were tested and certified by the I.S.P.E.S.L. Laboratory. (Safety Technology Departments and authorized by the Ministry of Labour and Social Affairs with specific AUTHORIZATIONS AND EXTENSIONS).

An efficient system for the control of weldings makes CONDOR scaffoldings with bushes reliable and trustworthy over the time.
The scaffolding with bushes is recommended for both renovations and new constructions.
